Tyan EPYC Transport SX TN70AB8026 B8026T70AV16E8HR 2U
Tyan EPYC Transport SX TN70AB8026 B8026T70AV16E8HR 2U
Warranty:
3 Years - Tyan
Dimensions (HxWxD):
3.43" x 17.72" x 27.56"
Material:
Steel
Weight:
66lbs gross, 42lbs net
Motherboard:
S8026GM2NRE (included)
Processor:
Single AMD EPYC 7000 Series Processor
Memory Slots:
16x DDR4 ECC 2666 MHz
Memory Capacity:
Up to 1TB RDIMM/LRDIMM
SATA Support:
2x SFF-8612 (16x SATA3)
NVMe Support:
4x SFF-8612 (8x NVMe)
M.2 Support:
2x PCI-E & SATA interface (22110/2280/2260/2242)
Expansion Slots:
2x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe OCP x16
Network:
2x Broadcom BCM5720 GbE, 1x Realtek RTL8211E (IPMI)
Video Out:
1x VGA (Aspeed AST2500)
External Bays:
16x 2.5" SATA3, 8x 2.5" NVMe
USB Ports:
3x USB 3.0 (2 rear, 1 TYPE-A), 2x USB 2.0 (front)
COM Ports:
1x DB-9, 1x header
Power Supply:
770 Watts, 1+1 Redundant, 80 plus Platinum
Cooling Fans:
4x 60MM
UPC Code:
635872043727
Manufacturer SKU:
B8026T70AV16E8HR
Price: $2,880.00
